T-2XD - T2X ROTATOR W/DCU1 CTRL, 110V

Hy-Gain | cód: T-2XD

US$ 1.209,95

Availability: Backordered

We currently have no stock in this product. If you wish to order this product it will be supplied on request. Please confirm the estimated shipping date by email sales@impextechnology.com before payment

Description
Tech Specs

The T-2XD Tailtwister Series II is designed for medium communications antenna arrays of up to 20 square feet wind load area. Low temperature grease, alloy ring gear indicator potentiometer, ferrite beads on potentiometer wires, new weatherproof AMP connectors plus 8-pin plug at control box, triple bearing race with 138 ball bearings for large load bearing strength, electric locking steel wedge brake, north or south center of rotation scale on meter, low voltage control, max mast of 2 1/16. It comes with a DCU-1 Digital Control Unit. Both operate at 110V.

T-2XD Rotator Specifications
Wind Load Capacity (inside tower)	20 square feet
Wind Load (w/ Mast Adapter)	10 square feet
Turning Power	1000 pounds
Brake Power	9000 pounds
Brake Construction	Electric Wedge
Bearing Assembly	Dual race/138 ball bearings
Mounting Hardware	Clamp Plates/Steel U-Bolts
Control Cable Conductors	8
Shipping Weight	28 pounds
Effective Movement (in tower)	3400 ft/lbs.
