LJ-155CA - 5 ELEMENT 15M LONG JOHN ON A 26 (7.9M) BOOM

Hy-Gain | cód: LJ-155CA

US$ 409,95
Availability: Backordered
We currently have no stock in this product. If you wish to order this product it will be supplied on request. Please confirm the estimated shipping date by email sales@impextechnology.com before payment
Indicar produto
Dúvidas?
Aumentar fonte Diminuir fonte
15/12 Meters, Five Elements, Exclusive 50 Ohm BetaMatch. Excellent DC Ground. Stainless steel hardware and clamps. Includes 12 Meter setting. BN-4000 Balun recommended.
This model is a 5-element beam optimized for maximum forward gain over the entire 15-meter or 12-meter band. Both the antenna and the "beta match" are factory pretuned for maximum performance. The elements are made of taper-swaged tubing. The bracket will fit a 2"-2 1/2" diameter mast. The electrical hardware is made from super strength stainless steel and all element tubing clamps are stainless. 3 0Copyright
3 1Classic
Frequency range 3 0Copyright : 21 MHz or 25 MHz (at your choice) 3 0Copyright
No. of elements 3 1Classic : 5 3 1Classic
Gain 3 1Classic : 7,6 dBd 3 1Classic
Front-to-Back ratio 3 2International : 20-25 dB 3 2International
Boom length 3 1Classic : 7,92 m. 3 1Classic
Reflector length 3 0Copyright : 7,6 m. 3 0Copyright
Turning radius 3 2International : 5,33 m. 3 2International
Wind surface area 3 1Classic : 0,483 m2 3 1Classic
Mast diameter 3 2International : 32-64 mm 3 2International
Balun 3 1Classic : not included, has to be ordered separately. See related articles below. 3 1Classic
Max. power 3 1Classic : 1,5 kW PEP
